9 Measurement
FLUXUS G809 9.3 Start of the measurement
101
UMFLUXUS_G809V2-2EN, 2020-06-25
9.2.5 Input of the error delay
The error delay is the time after which an error value will be sent to an output if no valid measured values are available.
This display will only be indicated if the list item edit is selected in Special Funct.\Dialogs/Menus\Error-val.
delay.
If the error delay is not entered, the damping factor will be used.
• Enter a value for the error delay.
• Press ENTER.
9.3 Start of the measurement
• Select the program branch Measuring.
• Press ENTER.
If the parameters in the program branch Parameter are
not valid or incomplete, the error message NO DATA! will
be displayed.
Activation of the channels
The channels for the measurement can be activated and
deactivated.
This display will not be indicated if the transmitter has only one measuring channel.
• Select a channel with key .
• Press key to activate or deactivate the channel.
• Press ENTER.
A deactivated channel will be ignored during the measurement. The parameters entered for this channel will remain un-
changed.
If the data logger or the serial interface is activated, the measuring point number has to be entered:
Example
output: current output
output range: 4…20 mA
Zero-Scale Val.: 0 m³/h
Full-Scale Val.: 300 m³/h
Test value = 150 m³/h (center of the measuring range, corresponds to 12 mA)
If the multimeter displays 12 mA, the current output functions correctly.
Output Options\...\I1:Error-val. delay
Measuring
Channel x
Meas.Point No.
Sound Path
Transd. Distance
Signal test
Transd. Distance
Measurement display
see annex A, p. 171
Measuring\Channel x
 the channel is activated
– the channel is deactivated
• the channel cannot be activated
Notice!
A channel cannot be activated if the parameters are not valid, e.g., if the parameters in the program branch Parameter
of the channel are not complete.
