16.7.4 Measurement with calculation channels
• Select the program branch Measuring.
• Press ENTER.
• Activate the necessary channels. The calculation channels are activated or deactivated the same way as measuring
channels.
• Press ENTER.
If a measuring channel that is needed for an activated calculation channel has not been activated, a warning will be dis-
played.
• Press ENTER.
Position the transducers for all activated measuring channels. The measurement will be started automatically.
If a calculation channel is activated, the HumanMux mode will be selected at the beginning of the measurement and the
values of the calculation channel will be displayed.
If the AutoMux mode is selected, the measured values of the measuring channels will be displayed alternately (but not the
measured values of the calculation channels).
• Press key to display the calculation function.
• Press key to display the measured values of the different channels.
16.8 Diagnosis with the help of the snap function
By means of the snap function it is possible to store measuring parameters which are useful for the evaluation of measur-
ing results or diagnosis purposes.
• Select Special Funct.\SYSTEM settings\Signal snap.
• Press ENTER.
Snap memory settings
• Select on to activate the snap function and off to deactivate it.
• Press ENTER.
• Select Install Snap.
• Press ENTER.
• Enter the number of the snap memory storage space.
• Press ENTER.
Measuring\CHANN: A B Y Z
Measuring\...\WARNING! CHANNEL B:INACTIV!
Special Funct.\SYSTEM settings\Signal snap
Special Funct.\SYSTEM settings\Signal snap\DSP-SignalSnap
Special Funct.\...\DSP-SignalSnap\Install Snap
Special Funct.\...\DSP-SignalSnap\Install Snap\Snap-Memory
Y:FLOW VELOCITY
53.41 m/s
To Next Page
