8 Start-up
FLUXUS G809 8.2 Switching on
83
UMFLUXUS_G809V2-2EN, 2020-06-25
8.2 Switching on
As soon as the transmitter is connected to the power supply, it is displayed which transducer has been detected at which
channel.
Afterwards, the serial number of the transmitter is displayed for a short time.
It is not possible to enter any data while the serial number is displayed.
After switching on the transmitter, the main menu is displayed in the default language. The language can be changed.
Operation state indication
The operation state is indicated by LEDs above the display.
8.3 Program branches
The following schema shows the program branches. For a detailed overview of the menu structure see annex A.
1
SYSTEM settings contains the following menu items:
• dialogs and menus
• measurement
• outputs
• storing
• snap
• network
• serial transmission
• miscellaneous
• clock settings
• libraries
Tab. 8.1: Operation state indication
LED off transmitter in idle state
LED lights green signal quality of the measuring channel sufficient for a measurement
LED lights red signal quality of the measuring channel not sufficient for a measurement
Parameter Measuring Options Special Funct.
Selection of a measuring channel Selection of measuring channels Selection of a measuring channel System settings
1
Pipe parameters Measuring point number Physical quantity Instrument information
Fluid parameters Number of sound paths Unit of measurement Print of measured values
Transducer type Transducer positioning Damping Deletion of measured values
Length of extension cable Measurement Output of measured value Program code
Consistency check
