9.1 Parameter input
The pipe and fluid parameters are entered for the selected
measuring point. The parameter ranges are limited by the
technical characteristics of the transducers and the trans-
mitter.
Select the program branch Parameter.
Press ENTER.
Select a channel for which the parameters are to be en-
tered (here: channel A).
Press ENTER.
The display will not be indicated if the transmitter has only
one measuring channel.
9.1.1 Input of pipe parameters
Outer pipe diameter/pipe circumference
Enter the outer pipe diameter.
Press ENTER.
An error message will be displayed if the entered parameter is outside the range. The limit is displayed.
Example: upper limit 1100 mm for the connected transducers and for a pipe wall thickness of 50 mm.
It is possible to enter the pipe circumference instead of the outer pipe diameter, see section 18.1.
If the input of the pipe circumference is activated and zero is entered in Outer Diameter, the menu item Pipe Cir-
cumfer. will be displayed. If the pipe circumference is not to be entered, press key BRK to return to the main menu and
start the parameter input again.
Notice!
The parameters will only be stored when the program branch Parameter has been edited in its entirety.
Parameter
for Channel x
Outer Diameter
Wall Thickness
Pipe Material
Lining
Roughness
Medium
Medium Temperat.
Transducer Type
Additional cable
see annex A, p. 168
Parameter\for Channel A
Parameter\Outer Diameter
Notice!
The inner pipe diameter (= outer pipe diameter - 2 × pipe wall thickness) will be calculated internally.
If the value is not within the inner pipe diameter range of the connected transducers, an error message will be displayed.
It is possible to change the lower limit of the inner pipe diameter for a given transducer type, see section 16.9.
Outer Diameter
1100.0 MAXIMAL
