14 Data logger
FLUXUS G809 14.1 Activation/Deactivation of the data logger
123
UMFLUXUS_G809V2-2EN, 2020-06-25
14 Data logger
The transmitter has a data logger which stores the data during the measurement.
The following data can be stored:
• date
• time
• measuring point number
• pipe parameters
• fluid parameters
• transducer data
• sound path (reflection or diagonal arrangement)
• transducer distance
• damping factor
• storage rate
• physical quantity
• unit of measurement
• values of the totalizers (in case the totalizers are activated)
• diagnostic values (in case the storing of diagnostic values is activated)
In order to store the data, the data logger has to be activated.
The available data logger can be displayed.
14.1 Activation/Deactivation of the data logger
• Select the channel for which the output is to be activated in the program branch Output Options.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
• Press ENTER until Store Meas.Data is displayed.
• Select yes to activate the data logger, no to deactivate it.
• Press ENTER.
14.2 Setting the storage rate
The storage rate is the frequency to transmit or store measured values. The storage rate is set separately. If the storage
rate is not set, the storage rate previously selected will be used.
The storage interval should be at least equal to the number of activated measuring channels, 4 s are recommended
• Select a storage rate or EXTRA.
• Press ENTER.
This display will only be indicated if Store Meas.Data and/or Serial Output are activated.
• Enter the storage rate if EXTRA was selected.
• Press ENTER.
Output Options\for Channel A
Output Options\...\Store Meas.Data
Output Options\...\Storage Rate
Output Options\...\Storage Rate\EXTRA
