13 Outputs
FLUXUS G809 13.2 Configuration of a frequency output as pulse output
121
UMFLUXUS_G809V2-2EN, 2020-06-25
• Select the measuring channel to be assigned to the frequency output as the source channel in the scroll list.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.This display will not be indicated if the
transmitter has only one measuring channel.
• Select as source item Measuring value in the scroll list (but not Impuls).
• Press ENTER.
If Measuring value is selected and the source item can be totalized, a request will be indicated whether the frequency
output is to be configured as a pulse output.
• Select yes.
• Press ENTER.
• Enter the upper limit of the frequency.
• Press ENTER.
The lower limit of the frequency and the error value will be set automatically to 0.5 Hz.
Activation of a frequency output
• Select the channel for which the output is to be activated in the program branch Output Options.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.This display will not be indicated if the
transmitter has only one measuring channel.
• Press ENTER until Frequency Output is displayed. Select yes to activate the output.
• Press ENTER.
• Enter the number of pulses that is to be assigned to the unit of measurement of the totalizer.
• Press ENTER.
Example: 1000 pulses correspond to 1 m³ of the totalized fluid.
The max. flow depending on the upper limit of the frequency and pulse value is indicated.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\...\Source chan. F1
Special Funct.\SYSTEM settings\Proc. outputs\...\Source item\Measuring value
Special Funct.\SYSTEM settings\Proc. outputs\...\Setup as pulse ?
Special Funct.\SYSTEM settings\Proc. outputs\...\Output MAX F1
Output Options\for Channel A
Output Options\...\Frequency Output
Output Options\...\Frequency Output\Pulses per unit
Output Options\...\Frequency Output\INFO: max flow= 3600.0 m3/h
