FLIR Duo - Page 93

FLI R Duo User Guide
436-0100-01-10, Rev. 200 Duo User Guide
Information on this page is subject to change without notice
88
Response command:
Instruction Application: UART /
TCP
Data flow: CS ---  G / A
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
Status Code
0x4001
0x2C
CRC
Instruction body
44 Bytes
CRC2
/ reserved
2 Bytes
Instruction body format:
Struct {
Negative temperature type, 1 - temperature type
Byte Reserve [3]; // Reserved
String strPN [20]; // part no
String strSN [20]; // serial no
};
CRC
CRC Description :
In CSP-TCP applications, the CRC is ignored
3.20.2 Restore factory settings
Request instruction
Instruction Application: UART /
TCP
Data flow: G / A ---  CS
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
0x00
0x4002
0x00
CRC
Instruction body
0 Bytes
CRC2
/ reserved
2 Bytes
air
CRC
CRC Description :
In CSP-TCP applications, the CRC is ignored
