Fluke 8808A User Manual

8808A
Users Manual
1-6
Symbols
Table 1-2 lists safety and electrical symbols that appear on the Meter or in this manual.
Table 1-2. Safety and Electrical Symbols
Symbol Description Symbol Description
W
Risk of danger. Important
information. See manual.
P Display ON / OFF and Meter reset.
X
Hazardous voltage. Voltage > 30 V
dc or ac peak might be present.
J Earth ground
B AC (Alternating Current) E Capacitance
F DC (Direct Current) G Diode
D
or
C
AC or DC (Alternating or Direct
Current)
I Fuse
R
Continuity test or continuity beeper
tone
Y
Digital signal
Y Potentially hazardous voltage U Maintenance or Service
T Double insulated < Recycle
h
Static awareness. Static discharge
can damage parts.
~
Do not dispose of this product as
unsorted municipal waste. Contact
Fluke or a qualified recycler for
disposal.
CAT II
Measurement Category II is for
measurements performed on
circuits directly connected to the
low voltage installation.
CAT I
Measurement Category I is for
measurements not directly
connected to mains.
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.ca

Fluke 8808A Specifications

General

Product type	Digital multimeter
Product color	Grey, White
Frequency range	0.2 - 2 kHz
AC current range	0.2 - 10 A
AC voltage range	0.2 - 750 V
DC current range	0.0002 - 10 A
DC voltage range	0.2 - 1000 V
Resistance range	200 - 100000000 Ω
Placement supported	Bench multimeter
Resistance resolution	0.001 Ω
Resolution (frequency)	0.0001 Hz
Resolution (AC current)	100 µA
Resolution (DC current)	1 µA
Resolution (DC voltage)	1 mV
Basic accuracy (frequency)	0.01%
Basic accuracy (DC current)	0.02 + 0.005
Basic accuracy (DC voltage)	0.015 + 0.003
Basic accuracy (resistance)	0.02 + 0.003
Display digits	5.5 digits

Weight and Dimensions

Depth	297 mm
Width	217 mm
Height	88 mm
Weight	2100 g
