Fluke 8808A User Manual

Operating the Meter from the Front Panel
List and Number Editors 3
3-23
Using the List Editor
The list editor is used to select the options described in Table 3-7. You may abort an edit
and return to normal operation at any time by pressing Q.
To use the list editor:
1. Select the option list that you want to edit by pressing the applicable button(s) as
indicated in Table 3-7. The option list type is shown in the secondary display and
the associated options are shown in the primary display.
2. Press Uor V to step through the options. (Hold either button to scroll
through the options.) As you step through the list, only the selected option is
shown in normal intensity (bright) while the others are dim.
3. When the desired option is shown, press R to select it. The selected option is
then displayed in normal intensity (bright).
Table 3-7. List Editor Options
To Set Buttons Options Annunciator
Touch Hold minimum
response level
Q then I
1 = 5 % of range
2 = 7 % of range
3 = 8 % of range
HoLd
RS-232 print-only mode
(if RS-232 interface is
selected)
K 0,1,2,5,10,20,50,100,
200, 500,1000,2000,
5000,10000,20000, or
50000
Print
RS-232 baud rate Q then K 300,600,1200,2400,
4800, 9600, or 19200
baud
Data bits
8
7
data
Parity options
E = Even
Odd = Odd
No = None
Par
Stop bit
1
2
StoP
Echo mode
On
Off
Echo
Trigger mode Q then J 1, 2, 3, 4, 5 tri
