Fluke 8808A User Manual

Operating the Meter Using the Computer Interface
Computer Interface Command Set 4
4-19
Function Modifier Commands and Queries
Table 4-10 describes function modifier commands and queries. A function modifier
causes the Meter to modify the normal operation of a measurement function or to perform
an action on a measurement before displaying a reading. For example, the relative
modifier (REL) causes the Meter to display the difference between a measured value and
the relative base. The results of function modifier commands are shown in the primary
display only.
Table 4-10. Function Modifier Commands and Queries
Command Description
DB Meter enters decibels modifier. Any reading shown in the primary display is in
decibels. An Execution Error is generated if the Meter is not in a volts ac
and/or dc function.
DBCLR Meter exits the decibels modifier and displays readings in normal units. Also
clears dB power, REL, and MIN MAX modifiers
DBPOWER Meter enters dB Power modifier if the reference impedance is set to 2, 4, 8, or
16 ohms and a voltage function has been selected. Otherwise an Execution
Error is generated. In dB Power, readings shown in the primary display are in
Watts.
Set dB reference impedance to a <value> shown in Table 4-10A. This value
corresponds to the reference impedance (ohms) indicated. If <value> is not a
value in Table 4-10A, an Execution Error is generated.
Table 4-10A. Reference Impedance Values
Value Ref Impedance Value Ref Impedance
DBREF <value>
1
2
3
4
5
6
7
8
9
10
11
2
4
8
16
50
75
93
110
124
125
135
12
13
14
15
16
17
18
19
20
21
150
250
300
500
600
800
900
1000
1200
8000
DBREF? Meter returns a <value> shown in Table 4-10A. This value corresponds to the
reference impedance indicated.
HOLD Meter enters Touch Hold function. (See “Touch Hold Function (HOLD)” in
Chapter 3 for more information.) If HOLD is sent when the Meter is already in
Touch Hold, a reading is forced and shown on the display.
HOLDCLR Meter exits Touch Hold and restores display to normal operation.
HOLDTHRESH
<threshold>
Sets HOLD measurement threshold to <threshold>.
<threshold> must be 1, 2, 3, or 4 (0.01 %, 0.1 %, 1 % or 10 %, respectively).
Any other value generates an Execution Error. See “Touch Hold Function
(HOLD)” in Chapter 3 for more information.
