Fluke 8808A User Manual

8808A
Users Manual
4-26
Table 4-17. Remote/Local Configuration Commands
Command Description
REMS Puts the Meter into remote (REMS) state mode without front panel lockout.
r is shown on the display.
RWLS Puts the Meter in remote with lockout state (RWLS) with front panel lockout.
r and L are shown on the display. When in RWLS, all front panel
buttons are disabled.
LOCS Puts the Meter is local state (LOCS) mode without lockout. All front panel
buttons are enabled.
LWLS Puts the Meter in local with lockout state (LWLS) mode. All front panel buttons
are disabled. L is shown on the display.
RS-232 Save / Recall System Configurations
Table 4-18 describes RS-232 save/recall system configuration commands, which are used
with the RS-232 interface to set up the remote/local configuration of the Meter.
Table 4-18. Save / Call System Configuration Commands
Command Description
Save <position> Saves the current running working status into <position>, where <position> is
1 through 6.
Call <position> Recalls the working status from <position>, where <position> is 1 through 6.
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.ca

Fluke 8808A Specifications

General

Product type	Digital multimeter
Product color	Grey, White
Frequency range	0.2 - 2 kHz
AC current range	0.2 - 10 A
AC voltage range	0.2 - 750 V
DC current range	0.0002 - 10 A
DC voltage range	0.2 - 1000 V
Resistance range	200 - 100000000 Ω
Placement supported	Bench multimeter
Resistance resolution	0.001 Ω
Resolution (frequency)	0.0001 Hz
Resolution (AC current)	100 µA
Resolution (DC current)	1 µA
Resolution (DC voltage)	1 mV
Basic accuracy (frequency)	0.01%
Basic accuracy (DC current)	0.02 + 0.005
Basic accuracy (DC voltage)	0.015 + 0.003
Basic accuracy (resistance)	0.02 + 0.003
Display digits	5.5 digits

Weight and Dimensions

Depth	297 mm
Width	217 mm
Height	88 mm
Weight	2100 g
