THE USER DISK
1.3.
A user disk can store information for different UUTs using a
named file directory for each. A WT file directory contains test
and troubleshooting programs, calibration data, and a system
configuration.
Once information for a particular type of UUT is stored on a
user disk, your system should use only that disk for all UUTs of
that type because the stored calibration data is unique to your
system.
The 9100A/9105A 3.5inch disk drives use industry standard
double-sided disks that can be obtained from Fluke or any
commercial computer store. Each disk stores over 650 kilobytes
of information.
To insert the disk into the drive, turn the disk so that the round,
metal hub is down and the arrow on the top-left comer of the
disk points toward the disk drive. Push the disk in until it
latches.
To remove the disk from the drive, press the black ejection
button on the drive.
Do not expose the recording surface under the spring-loaded
metal shield. Treat disks as you would treat audio cassettes. Do
not expose them to:
l
Moisture.
l
Extreme temperatures.
l
Direct sunlight.
l
Magnetic fields.
1-5
