A TYPICAL AUTOMATED TEST
5.1.
This procedure is a typical automated functional test of a UUT
called ABC.
1.
2.
3.
4.
5.
If you are using a
9105A,
check to be sure that the
user disk for testing your
UUI
is in Drive 2.
Connect the pod to the UUT.
Make other connections to the UUT if instructed to
do so.
Press the EXEC key and, if necessary, move the
cursor to the left-most field. The display will now
look like that below:
EXEC UUT PROGRAM
NOTE
The fields may not always be blank, but
they will change when you enter the
names you want.
Enter a UUT directory name into the first field using
the operator’s keypad. For this example, we will use
a UUT called ABC. Now the display looks like this:
EXEC UUT ABC PROGRAM
NOTE
The field for the program name may not
be blank, but it will change when you
enter the name you want.
-
5-2
