Section 2
The Operator’s Keypad
and Display
Figure 2-l shows the operator’s keypad and display. Functions
of the status lights and some of the keys are summarized in the
section following this figure.
You enter commands and information through the operator’s
keypad, and you get responses from the operator’s display.
This section shows you how to use the keypad, using the
SETUP MENU and EXEC keys as examples. Descriptions of
all the keys are available in Section 3 of the Technical User’s
Manual.
DISPLAY SAVER 2.1.
If there is no keyboard or display activity for approximately 20
minutes, the operator’s display goes blank, but no data is lost.
While the display is blanked, the top two status lights and
bottom two status lights blink. Pressing any key on the
operator’s keypad will restore the contents of the display, but the
keystroke is ignored.
2-l
