Fluke 9100A - Starting a RUN UUT Test

STARTING RUN UUT
7.7. -
To start a typical RUN UUT test:
1.
Connect the pod to the UUT.
2. Press the RUN UUT key and use the left arrow key
to move the cursor to the left-most field.
3. Press the SPECIAL softkey.
4. Move the cursor to the right-most field. If your pod
allows breakpoint addresses, you will see the
following softkey choices, one of which you should
use:
NOTE
If your pod does not allow breakpoints,
you will not see the following softkey
labels.
NO BREAK: This will cause the pod to start
executing stored instructions at the address specified.
The display should read something like:
RUN UUT SPECIAL ADDR FFFFO NO BREAK
BREAK: Pressing this softkey allows you to specify
a UUT memory address at which the RUN UUT test
is to stop.
7-2
