Fluke 9100A - Restoring a System Configuration

Restoring a System Configuration
4.3.2.
To restore a system configuration (all system settings) from a
user disk:
1. Press the SETUP MENU key and use the left arrow
key to move the cursor to the left-most field.
2. Press the RESTORE softkey.
3. Move the cursor to the next field and press the
SYSTEM softkey.
4. Move the cursor to the next field and press one of the
following softkeys:
USERDISK: If the system configuration was saved
in the USERDISK directory. The resulting display
should read:
RESTORE SYSTEM SETTINGS FROM USERDISK
UUT FILE: If the system configuration was saved in
a UUT directory.
5.
If you pressed the UUT FILE softkey in step 4, type
the UUT directory name; for example, type
“DEMO”. The resulting display should read:
RESTORE SYSTEM SETTINGS FROM UUT FILE DEMO
6.
Press the ENTER key to configure the system.
4-7
