Fluke 9100A - Pod Self-Test

Pod Self-Test 4.2.2.
The pod self-test comprehensively tests the pod. If it fails, an
error message is displayed to explain the cause of failure.
If you
do not understand the message, refer to the pod manual. To run
this test:
1. Make sure the pod is attached securely to the
mainframe. Insert the pod UUT connector into the
pod self-test socket, and lock it. Refer to the pod
manual and Getting Started for details.
2.
3.
4.
5.
6.
Press the MAIN MENU key, and use the left arrow
key to move the cursor to the left-most field.
Press the SELFTEST softkey.
Move the cursor to the next field, and press the POD
softkey. The display should read:
MAIN:
SELFTEST POD
Press the ENTER key to perform the self-test. If the
self-test fails, a failure message will appear on the
operator’s display. If this happens, check the pod
connections and repeat the test carefully following
any instructions. If the test still fails, the pod
requires service.
Remove the pod’s UUT connector from the self-test
socket and connect it to the UUT, which should be
powered down.
If necessary, refer to the pod
manual for connection details.
4-4
