I/O Module Self-Test
4.2.3.
The I/O module self-test is a pass/fail check that the module
concerned is connected to and communicating with the system.
To execute the test:
1.
Press the MAIN MENU key, and use the left arrow
key to move the cursor to the left-most field.
2. Press the SELFTEST softkey.
3. Move the cursor to the next field, and press the I/O
MOD softkey.
4. Move the cursor to the next field and identify the
module to be tested by a number (1 through 4).
For example, if module 2 is to be tested, press the
“2” key (a white key on the operator’s keypad). The
display should read:
MAIN: SELFTEST I/O MOD 2
5. Press the ENTER key. If the self-test fails, a failure
message will appear on the operator’s display. If
this happens, check the I/O module connections and
repeat the test carefully following any instructions.
If the test still fails, the I/O module requires service.
4-5
