Control-Line Leads, may be
connected to the UUT.
r
I/O Module
Clip Module, plugged into
I/O module
Grey Wire, indicates position
of pin 1 on UUT component
Clip Module, clipped over
UUT component
Clip Module’s Common Clip,
connected to UUT common
-
Figure 6-2: Using Clip Modules
