Getting Started
Saving Test Reports
2
2-13
Wall
outlet
PC
Transition
outlet
Patch cord
from hub
Patch cord
from PC
Horizontal
cross-connect
Horizontal
cabling
Telecommunications
closet
Work Area
Test Tool
Smart
Remote
TALK
Hub
Channel LIA
Channel LIA
oy03f.eps
Figure 2-5. Typical Test Connections for a Channel
