BLITZ
3.3 BASIC MACHINE VERSION COMPONENTS (Fig. 03-03)
1 - Machine bed complete with linear guides
2 - Heads complete with motors, blades and recirculating ball screws for head tilting
3 - Integral guard kit for cutting zone
4 - Pneumatic vices
5 - Sliding console with control panel and PC (only on version E)
6 - Electrical cabinet
7 - Pneumatic circuit at rear of fixed head and mobile head
8 - Air input filter
9 - Microdrop lubrication system
10 - Mobile head roller table
03-03
4
9
7
5
3
1
8
2
10
6
