43
BLITZ
G BG B
G BG B
G B
9 ADJUSTMENTS
N.B: The “BLADES FEED RATE” and “REGULATING THE BLADE LUBRICATION FLOW” adjustments are
normally set to standard values during testing in the assembly workshop. If any adjustments to the
above settings are necessary, proceed as described below.
9.1 BLADES FEED RATE (Fig. 09-01)
Turning knob “A” clockwise decreases the blade exit speed, while turning knob “A” counter clockwise
increases the blade exit speed.
09-01
A
