33
BLITZ
G BG B
G BG B
G B
1
05-20
5.7 CHIPS AND FUMES EXTRACTION
At the rear of each head, the machine is fitted with a connection for an extractor to take chips and fumes
generated by the cutting operation away from the area (see Ref. “1” Fig. 05-20).
If a type of exhauster is used which is different from those proposed by FOM Industrie, check that the system
has an adequate volumetric flow rate (min. flow rate. 500 m
3
/h at 150 mbar).
N.B. The extractor is installed by the user on his own sole responsibility.
CAUTION
It is forbidden to use the machine without a properly working exhauster connected.
