47
BLITZ
G BG B
G BG B
G B
To make very inclined external cuts (near to 12°), the fixing point of the external horizontal vice must be moved
so that it will not collide with the blade when it comes out.
To do this, undo release handle ‘1’ - Fig. 09-08 to remove the vice and fix it over hole ‘2’ - Fig. 09-08 in order
to obtain the configuration as in Fig. 09-09.
09-08
21
09-09
