TCP/IP Setting
Open the [MFR-TALM Web-based Control: Port Settings - TCP/IP page] and perform port
settings
Port
Menu
[Port Settings] - [TCP/IP]
Access
Method
IP Address
Port
Function
Web-based
Control
[TALM Settings]
Client
(MV
IP address)
(MV TCP/IP
port number)
TSL UMD
protocol V5.0
Tally out
Encode
DLE
Screen
No.
ID Range
ASCII /
Unicode(Kanji) /
Unicode(Import)
(Choose the
character set)
ON/OFF
(Set the
same as
in MV)
(Set the
same as
in MV)
Set the TSL ID
range to be sent
to MV
◆ Data transmission settings between HVS-4000 and MFR-TALM
<HVS-4000 side>
- To send tally data to the router from the switcher. Set TALLY ENABLE in the ROUTER
menu to ON.
- To receive name data from the router, set SIGNAL ENABLE in the ROUTER menu to
ON.
- Perform the TALLY COLOR and TALLY UNIT 1, 3 and 5 settings so that the MFR-TALM
unit can receive switcher tally data.
<MFR-TALM-side>
- Open the [MFR-TALM Web-based Control: HVS-TAL Protocol Reception page] and
perform the same tally settings as those in HVS-4000.
The tally settings in the MFR system must be entered in the [MFR-TALM Web-based
Control: Assign Tally page]. When using MFR-TALM for tally control, the [Main unit Web-
based Control: Tally System Settings page] and its subpages are all disabled.
Refer to your Multiviewer operation manual for the details on how to handle tally data on the
multiviewer.
