fos4X Blackbird OECD MDE1195 User Manual

3. Product Description
Data Blocks
Table 33: Data Blocks
Data block Name Description
1
Status word 1
Status of the measuring device. See Tab. 34: Bits
in Status word 1, page 39.
2
Status word 2
Extended status of the measuring device. See
Tab. 35: Bits in Status word 2, page 40.
3
Temperature
Temperature of the measuring device (single-
precision IEEE-754 floating point value).
4
Sensor Status
Status of the sensors. See Tab. 36: Bits in Sensor
Status, page 40.
5 … 20
Sensor
Wavelength
Wavelength of the sensors for each channel n.
See Tab. 37: Data Format for the Wavelengths,
page 41.
Data block 5 corresponds to channel n = 1.
Data blocks of non-existent channels contain the
value 0xfffffffe.
38 / 76
MDE1195_4-10_1.3.x_5.0_Blackbird
OECD_(9CH, PRN)-en-us
© fos4X 2020
