MIDI In/Out Data Format
VM200 User’s Guide 221
<Ch> 1-20:Ch 0x7f:All
<OnOff> 0:off 1:on
<< CH1-20 – Phase >>
command: f0 51 <DevId> 19 10 <Ch> 21 <Phase> f7.
request: f0 51 <DevId> 29 10 <Ch> 21 f7.
status: f0 51 <DevId> 39 10 <Ch> 21 <Phase> f7.
<Ch> 1-20:Ch 0x7f:all_Ch
<Phase> 0:Nor. 1:Inv.
<< CH1-20 – S/P DIF In>>
command: f0 51 <DevId> 19 10 <Ch> 26 <OnOff> f7.
request: f0 51 <DevId> 29 10 <Ch> 26 f7.
status: f0 51 <DevId> 39 10 <Ch> 26 <OnOff> f7.
<Ch> 1-20:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
<< CH1-20 – Rout:ST Buss >>
command: f0 51 <DevId> 19 10 <Ch> 30 <OnOff> f7.
request: f0 51 <DevId> 29 10 <Ch> 30 f7.
status: f0 51 <DevId> 39 10 <Ch> 30 <OnOff> f7.
<Ch> 1-20:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
<< CH1-20 – Rout:REC Buss >>
command: f0 51 <DevId> 19 10 <Ch> 31 <OnOff> f7.
request: f0 51 <DevId> 29 10 <Ch> 31 f7.
status: f0 51 <DevId> 39 10 <Ch> 31 <OnOff> f7.
<Ch> 1-20:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
<< CH1-20 : Adat Direct >>
command: f0 51 <DevId> 19 10 <Ch> 33 <OnOff> f7.
request: f0 51 <DevId> 29 10 <Ch> 33 f7.
status: f0 51 <DevId> 39 10 <Ch> 33 <OnOff> f7.
<Ch> 1-8:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
<< CH1-20 – Aux Send Level >>
command:
f0 51 <DevId> 19 10 <Ch> 41 <AuxId> <Vol> f7.
request: f0 51 <DevId> 29 10 <Ch> 41 <AuxId> f7.
status:
f0 51 <DevId> 39 10 <Ch> 41 <AuxId> <Vol> f7.
<Ch> 1-20:Ch 0x7f:all_Ch
<AuxId> 1:aux1 2:aux2 3:aux3 4:aux4 0x7f:all_aux
<Vol> 0-127:Vol
<< CH1-20 – Aux Post/Pre >>
command: f0 51 <DevId> 19 10 <Ch> 43 <AuxId>
<Post/Pre> f7.
request: f0 51 <DevId> 29 10 <Ch> 43 <AuxId> f7.
status: f0 51 <DevId> 39 10 <Ch> 43 <AuxId>
<Post/Pre> f7.
<Ch> 0x7f:all_Ch
<AuxId> 1:aux1 2:aux2 3:aux3 4:aux4 0x7f:all_aux
<Post/Pre> 0:post 1:pre
<< CH1-20 – Eff Send Level >>
command:
f0 51 <DevId> 19 10 <Ch> 49 <EffId> <Vol> f7.
request: f0 51 <DevId> 29 10 <Ch> 49 <EffId> f7.
status:
f0 51 <DevId> 39 10 <Ch> 49 <EffId> <Vol> f7.
<Ch> 1-20:Ch 0x7f:all_Ch
<EffId> 1:eff1 2:eff2 0x7f:all_eff
<Vol> 0-127:Volume
<< CH1-20 – Eff Post/Pre >>
command: f0 51 <DevId> 19 10 <Ch> 4b <EffId>
<Post/Pre> f7.
request: f0 51 <DevId> 29 10 <Ch> 4b <EffId> f7.
status: f0 51 <DevId> 39 10 <Ch> 4b <EffId>
<Post/Pre> f7.
<Ch> 0x7f:all_Ch
<EffId> 1:eff1 2:eff2 0x7f:all_eff
<Post/Pre> 0:post 1:pre
<< CH1-20 – Eq On >>
command: f0 51 <DevId> 19 10 <Ch> 50 <Band>
<OnOff> f7
request: f0 51 <DevId> 29 10 <Ch> 50 <Band> f7
status: f0 51 <DevId> 39 10 <Ch> 50 <Band>
<OnOff> f7
<Ch> 1-16:Ch 0x7f:all_Ch
<Band> 0x7f:all Band.
<OnOff> 0:off 1:on
<< CH1-20 – Eq Type(Q) >>
command:
f0 51 <DevId> 19 10 <Ch> 51 <Band> <Type> f7
request: f0 51 <DevId> 29 10 <Ch> 51 <Band> f7
status:
f0 51 <DevId> 39 10 <Ch> 51 <Band> <Type> f7
<Ch> 1-16:Ch 0x7f:all_Ch
<Band> 1:L 2:LM 3:HM 4:H 0x7f:All_Band.
<Type> 0:Hi/Lo_pass 1:Shelving 2-46:Parmetric_Q
<< CH1-20 – Eq Gain >>
command:
f0 51 <DevId> 19 10 <Ch> 52 <Band> <Gain> f7
request: f0 51 <DevId> 29 10 <Ch> 52 <Band> f7
status:
f0 51 <DevId> 39 10 <Ch> 52 <Band> <Gain> f7
<Ch> 1-16:Ch 0x7f:all_Ch
<Band> 1:L 2:LM 3:HM 4:H 0x7f:All_Band.
<Gain> 0-72:gain (36:0dB)
<< CH1-20 – Eq Freq >>
command: f0 51 <DevId> 19 10 <Ch> 53 <Band> <fL>
<fH> f7
request: f0 51 <DevId> 29 10 <Ch> 53 <Band> f7
status: f0 51 <DevId> 39 10 <Ch> 53 <Band> <fL>
<fH> f7
<Ch> 1-16:Ch 0x7f:all_Ch
<Band> 1:L 2:LM 3:HM 4:H 0x7f:all_Band.
<fL>(lower 7bit) + <fH>(upper 7bit) 0-239:F step.
<< CH1-20 – Eq Lib Recall >>
command: f0 51 <DevId> 19 10 <Ch> 5e <LibNo> f7
<Ch> 1-16:Ch 0x7f:All
<LibNo> 0-99:Eq lib number.
