222 VM200 User’s Guide
<< CH1-20 – Eq Lib Store >>
command: f0 51 <DevId> 19 10 <Ch> 5f <LibNo>
<Name..> f7
<Ch> 1-16:Ch 0x7f:All
<LibNo> 50-99:Eq lib number.
<Name..> Max 9byte lib Name ascii string.
<< CH1-20 – Ch Pair >>
command: f0 51 <DevId> 19 10 <Ch> 70 <OnOff> f7
request: f0 51 <DevId> 29 10 <Ch> 70 f7
status: f0 51 <DevId> 39 10 <Ch> 70 <OnOff> f7
<Ch> 1-20:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
<< CH1-20 – Fader Group >>
command: f0 51 <DevId> 19 10 <Ch> 71 <Grp> f7
request: f0 51 <DevId> 29 10 <Ch> 71 f7
status: f0 51 <DevId> 39 10 <Ch> 71 <Grp> f7
<Ch> 1-20:Ch 0x7f:all_Ch
<Grp> 0:off 1:A 2:B 3:C
<< CH1-20 – Mute Group >>
command: f0 51 <DevId> 19 10 <Ch> 72 <Grp> f7
request: f0 51 <DevId> 29 10 <Ch> 72 f7
status: f0 51 <DevId> 39 10 <Ch> 72 <Grp> f7
<Ch> 1-20:Ch 0x7f:all_Ch
<Grp> 0:off 1:A 2:B 3:C
<< CH1-20 – Ch Solo Safe >>
command: f0 51 <DevId> 19 10 <Ch> 73 <OnOff> f7
request: f0 51 <DevId> 29 10 <Ch> 73 f7
status: f0 51 <DevId> 39 10 <Ch> 73 <OnOff> f7
<Ch> 1-20:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
<< CH1-20 – Ch Recall Safe >>
command: f0 51 <DevId> 19 10 <Ch> 74 <OnOff> f7
request: f0 51 <DevId> 29 10 <Ch> 74 f7
status: f0 51 <DevId> 39 10 <Ch> 74 <OnOff> f7
<Ch> 1-20:Ch 0x7f:all_Ch
<OnOff> 0:off 1:on
Effects Commands
<< Eff Type >>
command: f0 51 <DevId> 1a <EffId> 10 <Type> f7
request: f0 51 <DevId> 2a <EffId> 10 f7
command f0 51 <DevId> 3a <EffId> 10 <Type> f7
<EffId> 1:eff1 2:eff2 0x7f:all_Ch
<Type> 0 to (EFFTYP_END - 1)
<< Eff Parameter >>
command: f0 51 <DevId> 1a <EffId> 11 <ParamNo>
<valL> <valH> f7
request: f0 51 <DevId> 2a <EffId> 11 <ParamNo> f7
command: f0 51 <DevId> 3a <EffId> 11 <ParamNo> f7
<EffId> 1:eff1 2:eff2 0x7f:all_Ch
<ParamNo> 1 to 12 or 0x7f:all_params.
<ValL> + <ValH>: 14bit parameter value.
<< Eff Name >>
command: f0 51 <DevId> 1a <EffId> 70 <Name..> f7
request: f0 51 <DevId> 2a <EffId> 70 f7
status: f0 51 <DevId> 3a <EffId> 70 <Name..> f7
<EffId> 1:eff1 2:eff2 0x7f:all_eff
<Name..> Max 9byte lib Name ascii string.
<< Eff Lib Recall >>
command: f0 51 <DevId> 1a <EffId> 72 <LibNo> f7
<EffId> 1:eff1 2:eff2 0x7f:all_eff
<LibNo> 0 to 99 eff lib number.
<< Eff Lib Store >>
command: f0 51 <DevId> 1a <EffId> 73 <LibNo> f7
<EffId> 1:eff1 2:eff2
<LibNo> 50 to 99 eff lib number.
Remote Commands
<< Key Remote >>
command: f0 51 <DevId> 1f 01 <KeyId> <OnOff> f7
<KeyId> 01-08:[Channel]On, 09:[Master]On,
11-18:[Channel]Solo, 19:[Master]Solo
1a:[Rec Buss]Solo, 21-28:[Channel]EQ Edit
31:[Fader Mode]Channel,
32-35:[Fader Mode]Aux1-4,
36-37:[Fader Mode]Eff1-2
38:[Key Mode]Routing/Phase
39:[Key Mode]Pair/Group
3a:[Key Mode]Ch View
3b:[Key Mode]Channel/Meter
41:
[Current Scene Status], 42:[Setup]System
43:[Setup]Midi, 51:[Page Sel]1-8
52:[Page Sel]9-16, 53:[Page Sel]17-20
61:[Selected EQ]EQ On
62:[Selected EQ] Library Recall
63:[Selected EQ]Library Store
64:[Eff Edit]Eff1, 65:[Eff Edit]Eff2
66:[Eff Edit]Library Recall
67:[Eff Edit]Library Store
68:[Scene Memory]Recall
69:[Scene Memory]Store
71:<-/-1, 72:+1->, 73:Exit, 74:Enter
<OnOff> 0:off 1:on
<< Key Remote >>
command: f0 51 <DevId> 1f 02 <EncId> <EncVal> f7
<EncId> 01-12:Encoder (top raw from left:1-4,
bottom raw from left: 9-12), 11:Data
<EncVal> 0-3f:-64 – -1, 40-7f:+1 – +64
0–3f:variation=0x40-Val
40–7f:variation=Val-0x3f
