MIDI In/Out Data Format
VM200 User’s Guide 223
4. Bulk Dump (& Request)
<Reception>
Bulk Dump is received when [BLK DMP EQ.] is set to ON and when [RX CH] and DEVICE No.
match.
The received Bulk Dump is immediately written into the specified memory.
When the VM200 receives the Bulk Dump Request, it immediately transmits Bulk Dump.
<Transmission>
Bulk Dump is transmitted on the channel specified by [TX CH] when you operate the key in the
[BULK DUMP] page.
In response to Bulk Dump Request, Bulk Dump is sent on the channel specified by [RX CH].
4-1. Bulk Dump Request
<< Setup Bulk Dump Request >>
f0 51 <DevId> 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 01 <Item> f7
<Item> 01:System, 02:Midi, 03:Locate, 127:All Setup
<< Scene Memory Bulk Dump Request >>
f0 51 <DevId> 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 02 <MemNo> f7
<MemNo> 0: Edit Buffer, 1 – 100: UserMemory, 127: All User Memory
<< Eff Library Bulk Dump Request >>
f0 51 <DevId> 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 03 <LibNo> f7
<LibNo> 50 – 99: User Library, 127: All User Library
<< Eq Library Bulk Dump Request >>
f0 51 <DevId> 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 04 <LibNo> f7
<LibNo> 50 – 99: User Library, 127: All User Library
<< PGM Table Bulk Dump Request >>
f0 51 <DevId> 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 05 00 f7
<< CTL Table Bulk Dump Request >>
f0 51 <DevId> 2B ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 06 00 f7
4-2. BULK DUMP OUT FORMAT
<< Setup Bulk Dump Format >>
f0 51 <DevId> 3B <Byte Count L> <Byte Count H> ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 01 <Item>
<Data> --- <Data> <Check Sum> f7
<< Scene Memory Bulk Dump Format >>
f0 51 <DevId> 3B <Byte Count L> <Byte Count H> ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 02 <MemNo>>
<Data> --- <Data> <Check Sum> f7
<MemNo> 0: Edit Buffer, 1 – 100: UserMemory
<< Eff Library Bulk Dump Format >>
f0 51 <DevId> 3B <Byte Count L> <Byte Count H> ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 03 <LibNo>>
<Data> --- <Data> <Check Sum> f7
<LibNo> 50 – 99: User Library
<< Eq Library Bulk Dump Format >>
f0 51 <DevId> 3B <Byte Count L> <Byte Count H> ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 04 <LibNo>>
<Data> --- <Data> <Check Sum> f7
<LibNo> 50 – 99: User Library
<< PGM Table Bulk Dump Format >>
f0 51 <DevId> 3B <Byte Count L> <Byte Count H> ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 05 00
<Data> --- <Data> <Check Sum> f7
<< CTL Table Bulk Dump Format >>
f0 51 <DevId> 3B <Byte Count L> <Byte Count H> ’V’ ’M’ ’2’ ’0’ ’0’ ’A’ 06 00
<Data> --- <Data> <Check Sum> f7
* “Byte Count” is the number of bytes counted from the byte following <Byte Count> up to the
byte before <Check Sum>.
* “Check Sum” covers after <Byte Count> before <Check Sum>, with all EOR being removed.
