1 IP Configuration
1.1 IP IP Configuration without VLAN configurations
The IP configuration is necessary to get access to the webinterface of the switch. If there are no additional VLAN
configurations, only the VLAN1 interface must be configured. If there are VLAN configurations, may its necessary to configure
additional IP addresses for the other VLANs.
To setup a static IP address for the switch, it is necessary to click on IP configuration.
This leads to the menu IP configuration > IP Interfaces > IPv4 Interfaces.
Figure 8: Interface IP configuration page
In this menu the configuration of the interfaces can be seen. For the first configuration a new entry must be added.
Therefore, click on “Add” and enter the configuration information.
Figure 9: IP configuration Popup
With a click on “Apply” the configuration will be setup in the running configuration.
Now use the web browser with the new configured IP address for further configuration.
If the configuration works properly, the configuration must be saved in the startup configuration.
The save process is described in the section file management.
Note
VLAN1 is the default interface.
If there are no specific VLAN configurations,
use this interface.
DATALIGHT Switch 12+4-Port 1000
8
