Chapter 2 Robot Assembly
█ www.freenove.com
3. Mount two servos to the below acrylic parts with M2*10 screws and M2 nuts.
Assembly diagram
After assembly
4. Mount the two set of acrylic parts above with M3*12 screws and M3 nuts.
5. Mount two servos to the below acrylic parts with M2*10 screws and M2 nuts.
Note: The direction is different from that in No.2!
Assembly diagram
After assembly
M2*10 screw
M2 nut
M3x12 screw
M3 nut
M2x10 screw
M2 nut
