Chapter 2 Robot Assembly
www.freenove.com █
6. Mount two servos to the below acrylic parts with M2*10 screws and M2 nuts.
Note: The direction is different from that in No.3!
Assembly diagram
After assembly
7. Mount the two set of acrylic parts abovw with M3*12 screws and M3 nuts.。
Note: The direction is different from that in No.4!
Left
Right
M2*10 screw
M2nut
M3x12 screw
M3 nut
