Battery Access
The batteries may be located below the driver’s door,
underneath the steps. To access the batteries lo-
cated under the steps, turn the latch on the front of
the battery-box cover clockwise to release the catch,
then lift the cover and step assembly upwards and
outwards to expose the plastic battery box. Release
the catch on the plastic cover, then remove it to ac-
cess the batteries. See
Fig. 3.2.
11/11/2009 f545613
1
1. Latch
Fig. 3.2, Battery Compartment (under driver’s door)
Electrical System
3.2
