faults, the total number of faults is displayed in pa-
renthesis next to the affected controller. To view spe-
cific active faults, press the upper half of the ICU4Me
control switch on the dash. Press the upper half of
the ICU4Me control switch to toggle between the text
description and the failure code for each selected
fault.
Service Information
Using this menu, the driver can enable, disable, and
set service intervals for engine miles or engine
hours. After enabling service intervals, select interval
unit (miles or hours), and the interval duration.
Settings
The settings menu contains the controls for the fol-
lowing settings:
•
Display (includes brightness, contrast, display
light, and night mode settings)
•
Gauge select
•
Language
•
Temperature warning enable/disable
•
Units
The Gauge Select submenu allows the driver to se-
lect certain gauge values for display in the message
field while driving. See
Fig. 4.25. Use the + and –
switches on the dash to scroll through the list of
available gauges, then press the upper half of the
ICU4Me control switch to select a desired gauge.
The ICU4Me control switch can also be used to un-
check boxes if necessary.
ICU Information
The ICU Information screen displays the part num-
bers for the instrument cluster and software.
Roll Stability System
The roll stability system may entail Roll Stability Advi-
sor (RSA) only, or it may also include Roll Stability
Control (RSC).
A decal (
Fig. 4.26) on the auxiliary dash panel and
an amber-colored dash indicator light (
Fig. 4.27), in-
dicate that the vehicle is equipped with roll stability
system components.
NOTE: The roll stability system indicator is lo-
cated on the lightbar in place of the WHEEL
SPIN indicator.
1/3
Accelerator Pedal
Problem Detected
Diagnostics
MENU
BACK
Active
Engine (3)
1/3
ABS (1)
Engine (3)
MENU
BACK
1/2
Active (12)
Historic (0)
MENU
BACK
Indicates when to press
the MENU BACK switch
Indicates when to press
the ENTER switch
05/30/2012 f611194
Menu
Diagnostics
MSF (1)
Menu
Diagnostics
Active
Fig. 4.24, Diagnostics Menu Navigation, ICU4Me
06/26/2012 f611195
1/6
Axle Temp
Air Pressure
Engine Oil Temp
Menu
Settings
Gauge Disp.
x
Fig. 4.25, Selecting Gauges to Display, ICU4Me
Instruments
4.25
