Baggage Compartment Lights
Baggage compartment lights are on all sleeper cabs.
One light is located on each side of the cab on the
underside of the lower bunk and illuminates the bag-
gage compartment. Both lights turn on when either
baggage compartment door is opened. The lights
also come on when the lower bunk is raised. See
Fig. 8.5.
11/19/2009 f611085
1
2
1. Overhead Light 2. Sleeper Curtain
Fig. 8.4, Overhead Light
09/29/95 f541139
1
2
3
1. Under-Bunk Light
2. Bunk
3. Switch
Fig. 8.5, Baggage Compartment Light
Cab Features
8.2
