4.2 Positioning
NOTICE
Damage to components if handled incorrectly
❒
Follow the transport instructions on the packaging
❒ Transport components with care to avoid damage
❒ Protect the packaging against damp conditions
❒ Pay attention to the pallet's centre of gravity when lifting
❒
Position a fork-lift or similar lifting device at the pallet and bring in the components
If the boiler cannot be brought in on the pallet:
❒ remove the cardboard and take the boiler off the pallet
⇨ See "Remove boiler from pallet" [page 25]
Positioning using a crane
❒ Attach the crane hook to the attachment point correctly and position the boiler
4.2.1 Temporary storage
If the system is to be assembled at a later stage:
❒
Store components at a protected location, which is dry and free from dust
➥ Damp conditions and frost can damage components, particularly electric ones!
4
Assembly
Positioning
24 Froeling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.at
