4.3 Setting up in the boiler room
4.3.1 Remove boiler from pallet
❒ Remove the cardboard with the controller from the boiler and put in a safe place
❒
Lift the cardboard box with the insulation from the pallet
❒ Remove the transport locks
➥ A total of four screws, left/right, front/rear
❒
Lift boiler from pallet
TIP: use Froling’s KHV 1400 boiler lifting system to help remove the pallet!
4.3.2 Moving the boiler in the boiler room
❒ Position a fork-lift or similar lifting device with a suitable load-bearing capacity at
the base frame
❒
Lift and transport to the intended position in the installation room
➥ Observe the minimum distances in the boiler room.
Assembly
4
Setting up in the boiler room
Installation Instructions S3 Turbo | M1081217_en 25
