Item Quantity
[units]
Name Item Quantity
[units]
Name
1 1 Insulated door, complete 21 1 Controller box, complete
2 2 Magnetic latches 22 2 Hexagonal screw M6 x 100
3 1 Control, complete 23 1 Insulating cover, back
4 1 U-plate – S3 Turbo 40/45 24 1 Controller cover
5 1 Lower door bracket 25 1 Heat insulation mat, top/front
6 1 Cover plate, insulated door, bottom 26 1 Bracket, right
7 1 Complete floor insulation 27 1 Hinge pin, insulated door
8 1 Insulation cover plate, left 28 1 Insulating side panel, right, complete
9 2 Counter plate for magnetic latches 29 1 Insulation cover plate, right
10 1 Insulating side panel, left, complete 30 1 Side cleaning door, complete
11 1 Blanking plate, side cleaning door 31 1 Door handle, cleaning door
12 1 Cover plate 32 1 Round-head screw M8 x 30
13 1 Bracket, left 33 1 Cover plate
14 1 Thermal insulation, rear 34 2 Air flap manual controller
(only for S-Tronic Plus)
15 1 Back panel, complete 35 2 Air flap handle
(only for S-Tronic Plus)
16 2 Cover plate for ID fan 36 1 Sticker, "Primary air actuator"
(only with S-Tronic Lambda)
17 1 Heat insulation mat, top 37 1 Sticker, "Secondary air actuator"
(only with S-Tronic Lambda)
18 1 Upper spacer plate 38 1 Torque support
(only with S-Tronic Lambda)
19 1 Door contact switch incl. cable 39 2 Servo-motor LM 24AP5-F/300.1
(only with S-Tronic Lambda)
20 1 Heat insulation mat, top/rear
Assembly
4
Installing the boiler
Installation Instructions S3 Turbo | M1081217_en 33
