Item Quanti
ty
[units]
Description Item Quanti
ty
[units]
Description
1 1 Insulated door, complete 22 2 Hexagonal screw M6 x 100
2 2 Magnetic latches 23 1 Insulating cover, back
3 1 Control, complete 24 1 Controller cover
4 1 U-plate – S3 Turbo 36/45 25 1 Heat insulation mat, top/front
5 1 Lower door bracket 26 1 Bracket, right
6 1 Cover plate, insulated door, bottom 27 1 Hinge pin, insulated door
7 1 Complete floor insulation 28 1 Insulating side panel, right, complete
8 1 Insulation cover plate, left 29 1 Insulation cover plate, right
9 2 Counter plate for magnetic latches 30 1 Side cleaning door, complete
10 1 Insulating side panel, left, complete 31 1 Door handle, cleaning door
11 1 Blanking plate, side cleaning door 32 1 Round-head screw M8 x 30
12 1 Cover plate 33 1 Cover plate
13 1 Bracket, left 34 1 Cover plate, actuator cable
14 1 Thermal insulation, rear 35 1 “Primary air actuator” label
15 1 Back panel, complete 36 1 “Secondary air actuator” label
16 2 Cover plate for ID fan 37 1 Torque support
17 1 Heat insulation mat, top 38 2 Servo-motor LM 24AP5-F/300.1
18 1 Upper spacer plate 39 2 Cover, terminal block
19 1 Door contact switch incl. cable 40 2 Terminal block
20 1 Heat insulation mat, top/rear 41 16 Cable leadthrough
21 1 Controller box, complete 42 2 Cover plate, cable duct
3
Assembly
Installing the boiler
