3.3 Setting up in the boiler room
3.3.1 Remove boiler from pallet
❒ Cut through and remove tension bars with diagonal cutting pliers
❒
Remove the wooden slats which are fixed with nails
➥ In total 8 nails left/right, front/rear
❒ Lift boiler off pallet
3.3.2 Moving the boiler in the boiler room
❒ Position a fork-lift or similar lifting device with a suitable load-bearing capacity at
the base frame
❒
Lift and transport to the intended position in the installation room
➥ Observe the minimum distances in the boiler room.
S3 Turbo 30/50
3
Assembly
Setting up in the boiler room
36 Froling GesmbH | A-4710 Grieskirchen | www.froeling.com
