12
PlasmaModule 10 is generator-compatible, provided the maximum apparent power
delivered by the generator is at least 1.5 kVA.
NOTE! The voltage delivered by the generator must never exceed the upper or
lower limits of the mains voltage tolerance range. Details of the mains voltage
tolerance are given in the section “Technical data”.
Generator-
powered operati-
on
Digital plasma
gas control
Important! Before operating for the first time, mount the supply pressure regulator,
supplied separately, on the rear of the PlasmaModule 10. When mounting, pay attention
to the sealing ring in the supply pressure regulator.
For the digital plasma gas regulator in PlasmaModule 10 to reach the maximum gas
flow, the following requirements must be met:
- If the plasma gas supply has a pressure regulator, open it fully after connecting the
gas hose.
- The pressure regulator with metering tube (item number: 43,0011,0008) is not
suitable, as it does not allow a sufficient supply pressure.
- Where the plasma and shielding gas are supplied by gas cylinders:
use separate gas cylinders for plasma gas and shielding gas.
The digital PlasmaModule 10 is fitted with a digital plasma gas regulator as standard.
WARNING! Plasma gas is colourless and odourless, is hazardous to health
and can cause asphyxiation. If the following instructions are not observed, after
welding has finished there is a danger of the control valve not closing fully.
Colourless and odourless plasma gas may escape undetected.
- Use the digital PlasmaModule 10 only in conjunction with the standard
supply pressure regulator.
- Never alter the adjusting screw on the supply pressure regulator. If the
adjusting screw is altered, Fronius accepts no liability for resulting damage.
- Do not exceed the maximum supply pressure of 9 bar (130 psi).
