33
Mains voltage 230 V
Mains voltage tolerance -20% / +15%
Mains fuse protection (slow-blow) 16 A
Mains connection
1)
Z
max
on PCC
2)
= 142 mOhm
Primary contin. power (100% d.c.
3)
) 0.9 kVA
Cos phi 0,99
Plasma current range 3.0 - 30.0 A
Pilot current at 10 min / 40°C (104°F) 100% d.c.
3)
30 A
Open-circuit voltage 88 V
Standardised working voltage 10.1 - 11.2 V
Striking voltage (U
p
) 9.5 kV
The arc striking voltage is designed for manual guided operation.
Protection IP 23
Type of cooling AF
Insulation class B
Dimensions l/w/h 505/180/344 mm
19.88/7.09/13.54 in.
Weight 14,2 kg
33.31 lbs.
Marks of conformity S, CE
1) To 230/400 V, 50 Hz public supply mains
2) PCC = point of common coupling
3) d.c. = duty cycle
Technical data
NOTE! Inadequately dimensioned electrical installations can lead to serious
damage. The mains lead and its fuse protection must be rated accordingly. The
technical data shown on the rating plate shall apply.
Technical data
General remarks
