Installation and function of mechanically-controlled
wire cutter (option)
How the mechani-
cally-controlled
wire cutter works
If a torch neck pushes the valve lever (1) to
the side by more than 15° with the gas
nozzle, the wire cutter is activated and the
wire electrode is cut.
NOTE!
The wire electrode is cut while the torch
neck is moving.
Maximum wire di-
ameter
Wire electrodes with a diameter of up to 1.6 mm (0.063 in.) can be cut by the wire cutter.
Installing the me-
chanically-con-
trolled wire cutter
1
NOTE!
Use the fixings supplied with the wire
cutter for the assembly shown.
(1)
1
