43
EN
Installation and function of electrically-controlled
wire cutter (option)
How the electri-
cally-controlled
wire cutter works
The electrically-controlled wire cutter opens and closes when there is an active signal from
the robot control.
Maximum wire di-
ameter
Wire electrodes with a diameter of up to 1.6 mm (0.063 in.) can be cut by the wire cutter.
Installing the
electrically-con-
trolled wire cutter
NOTE!
Use the fixings supplied with the wire cutter for the work described below.
1
2
* Use a suitable adapter to connect
the wire cutter compressed air hose
to the cleaning device.
1
2
3
1
*
2
