Fronius Selectiva Series - Page 21

21
EN
If the wall bracket bar (2) is not required,
store it on the rear of device and secure it
using wing nuts (7).
Alternatively, the wall bracket bar (2) can
also be stored on the right-hand side of the
device. It is secured using TX25 screws (8)
and a tightening torque of 3 Nm.
(7)(2)(7)
(8) (8) (2)
