17
Level codelock P2 The Transtig 1600 machine comes with an electronic codelock. The codelock is not
activated when the machines leave the factory. Whenever you change the numerical
combination, keep a written note of it! Only a 3-digit code may be used. (On new machi-
nes, the code number is set to “321”)
1. Procedure
- Access "Codelock level P2"
- "Cod _?_" appears on the display
- Enter the present code (on new machines, this is 321)
- Set the desired numbers with dial I
H
(15)
- Conform each numeral with button (4)
- Repeat this procedure twice, until "Cod OFF" or "Cod ON" appears on the
display
2. Change and activate code
a.) Display reads „Cod OFF“:
- Using the torch trigger, switch to „Cod ON“ (see Pt. 2b for further instructions)
b.) Display reads „Cod ON“:
- Use function button (4) to change to „CYC__?“
CYC (cycle) indicates how often the unit can be switched
on without the code having to be entered
- Using the torch trigger, set the number of cycles
- Press function button (4) until „Cod ?---“ appears on the display
- Enter the new numerical code
- Enter 0-9/A-H using the torch trigger
- Confirm each numeral with function button (4)
- Repeat this procedure twice, until all 3 digits of the new code have been
entered
- Press the torch trigger
- The display reads „Cod _-_“
- Re-enter the new code, for control purposes:
- set the desired numerals with dial I
H
(15)
- confirm each numeral with button (4)
- repeat this procedure twice, until the code has been entered
- the third time you confirm, the code is automatically stored in the memory
NOTE! If you enter the code incorrectly three times in a row (ERR), the machine
will automatically switch to „LOC“. You must switch the machine off and repeat
the entire procedure!
- Machine is now ready for use
3. Deactivate code
- Display reads „Cod ON“
- Using the torch trigger, switch to „Cod OFF“
- Press button (4) to shift to „PRO“
- To deactivate the present code, press the torch trigger
- Machine is now ready for use
Important! From now on, the code is 321 again!
Machine start-up when codelock is activated
- Switch on at the master switch (1). The display („Cod _?_“) now asks you to enter
the code number
- Enter the first numeral of the combination using dial I
H
(15)
- Confirm this numeral with function button (4)
- Repeat this procedure twice more
- Machine is now ready for use
