TTB 220 G TTB 220 A G F TTB 220 P G F
DC welding current
at 10 min / 40 °C
(104 °F)
35% D.C.
1)
/ 220 A 35% D.C.
1)
/ 220 A 35% D.C.
1)
/ 220 A
60% D.C.
1)
/ 170 A 60% D.C.
1)
/ 170 A 60% D.C.
1)
/ 160 A
100% D.C.
1)
/ 130
A
100% D.C.
1)
/ 130
A
100% D.C.
1)
/ 130
A
AC welding current
at 10 min / 40 °C
(104 °F)
35% D.C.
1)
/ 180 A 35% D.C.
1)
/ 180 A 35% D.C.
1)
/ 170 A
60% D.C.
1)
/ 130 A 60% D.C.
1)
/ 120 A 60% D.C.
1)
/ 120 A
100% D.C.
1)
/ 100
A
100% D.C.
1)
/ 100
A
100% D.C.
1)
/ 100
A
Shielding gas
(Standard EN 439)
Argon Argon Argon
Electrode diameter 1.0 - 4.0 mm
(0.039 - 0.158 in.)
1.0 - 4.0 mm
(0.039 - 0.158 in.)
1.0 - 4.0 mm
(0.039 - 0.158 in.)
TTB 220 P S G
2)
TTB 220 P G TFC
3)
TTB 260 G
DC welding current
at 10 min / 40 °C
(104 °F)
35% D.C.
1)
/ 220 A 35% D.C.
1)
/ 220 A 35% D.C.
1)
/ 260 A
60% D.C.
1)
/ 170 A 60% D.C.
1)
/ 170 A 60% D.C.
1)
/ 200 A
100% D.C.
1)
/ 130
A
100% D.C.
1)
/ 130
A
100% D.C.
1)
/ 150
A
AC welding current
at 10 min / 40 °C
(104 °F)
35% D.C.
1)
/ 180 A 35% D.C.
1)
/ 180 A 35% D.C.
1)
/ 200 A
60% D.C.
1)
/ 130 A 60% D.C.
1)
/ 130 A 60% D.C.
1)
/ 160 A
100% D.C.
1)
/ 100
A
100% D.C.
1)
/ 100
A
100% D.C.
1)
/ 120
A
Shielding gas
(Standard EN 439)
Argon Argon Argon
Electrode diameter 1.0 - 4.0 mm
(0.039 - 0.158 in.)
1.0 - 4.0 mm
(0.039 - 0.158 in.)
1.0 - 4.0 mm
(0.039 - 0.158 in.)
1)
D.C. = Duty cycle
2)
Articulated torch body
3)
TFC clamping system
Water-cooled
torch body -
TTB 180, TTB
300, TTB 400,
TTB 500
TTB 180 W TTB 300 W
DC welding current
at 10 min / 40 °C (104 °F)
60% D.C.
1)
/ 180 A 60% D.C.
1)
/ 300 A
100% D.C.
1)
/ 140 A 100% D.C.
1)
/ 230 A
AC welding current
at 10 min / 40 °C (104 °F)
60% D.C.
1)
/ 140 A 60% D.C.
1)
/ 250 A
100% D.C.
1)
/ 110 A 100% D.C.
1)
/ 190 A
Shielding gas
(Standard EN 439)
Argon Argon
Electrode diameter 1.0 - 3.2 mm
(0.039 - 0.126 in.)
1.0 - 3.2 mm
(0.039 - 0.126 in.)
96
