Fronius TTB 80 G User Manual

Gas-cooled ho-
sepack –
THP 160i,
THP 220i,
THP 260i
THP 160i THP 220i
DC welding current
at 10 min / 40 °C (104 °F)
35% D.C.
1)
/ 160 A 35% D.C.
1)
/ 220 A
60% D.C.
1)
/ 120 A 60% D.C.
1)
/ 170 A
100% D.C.
1)
/ 90 A 100% D.C.
1)
/ 130 A
AC welding current
at 10 min / 40 °C (104 °F)
35% D.C.
1)
/ 120 A 35% D.C.
1)
/ 180 A
60% D.C.
1)
/ 90 A 60% D.C.
1)
/ 130 A
100% D.C.
1)
/ 70 A 100% D.C.
1)
/ 100 A
Length
4.0 / 8.0 m
(13 ft. 1.48 in. / 26 ft.
2.96 in.)
4.0 / 8.0 m
(13 ft. 1.48 in. / 26 ft.
2.96 in.)
Maximum permitted open circuit
voltage (U
0
)
113 V 113 V
Maximum permitted striking voltage
(U
P
)
10 kV 10 kV
THP 260i
DC welding current at 10 min / 40 °C (104 °F)
35% D.C.
1)
/ 260 A
60% D.C.
1)
/ 200 A
100% D.C.
1)
/ 150 A
AC welding current at 10 min / 40 °C (104 °F)
35% D.C.
1)
/ 200 A
60% D.C.
1)
/ 160 A
100% D.C.
1)
/ 120 A
Length
4.0 / 8.0 m
(13 ft. 1.48 in. / 26 ft.
2.96 in.)
Maximum permitted open circuit voltage (U
0
) 113 V
Maximum permitted striking voltage (U
P
) 10 kV
1)
D.C. = Duty cycle
