CAUTION!
Danger due to excessive charging current!
Fires or damage to the in-house installation may result.
▶
Observe the maximum permissible current at the connected socket.
▶
If the maximum charging current is not known, charge with the lowest pos-
sible charging current.
▶
Only use original adapters. An automatic reduction of the charging current to
16 A by plugging in the adapter is only possible in conjunction with the ori-
ginal adapters.
CAUTION!
Danger due to heat generation on the device!
The build-up of heat can lead to lasting damage and even fire.
▶
Never cover the device during charging.
▶
Unwind the cable completely from a cable drum.
▶
Observe the correct installation position.
Never pull the plug out of the plug connection by the cable!
Observe the specifications of the grid operator regarding 1‑phase charging and
the asymmetrical network load that may result.
The device has a built-in residual current protection module with residual current
detection (20 mA AC and 6 mA DC). This means that no upstream type B resid-
ual-current circuit breaker is required. A separate type A residual-current circuit
breaker and an automatic circuit breaker must be connected upstream for each
Wattpilot.
The device may only be operated at the following connections:
-
CEE red 32 A, 3-phase, 400 V
-
CEE red 16 A, 3-phase, 400 V
-
With original adapters:
-
CEE red 16 A, 3-phase, 400 V
-
CEE red 32 A, 3-phase, 400 V
-
CEE blue 16 A, 1-phase, 230 V
-
Earthed plug 16 A, 1-phase, 230 V
In case of defective adapters or defective CEE plugs, send the device in for re-
pair.
Suitable invert-
ers
Compatibility with the connected devices, suitable data communication and a
Fronius Smart Meter at the feed-in point are prerequisites for using some Watt-
pilot functions (e.g. PV surplus).
Suitable Fronius inverters
-
Fronius GEN24
-
Fronius Symo Hybrid
-
Fronius SnapINverter (except light versions)
-
Fronius IG*
-
Fronius IG Plus*
-
Fronius IG TL**
-
Fronius CL*
13
EN
