Fronius Wattpilot Go 11 J 2.0 User Manual

Technical data
Wattpi-
lot Go 11 J 2.0
Fronius Wattpilot – technical data Go 11 J 2.0
Max. charging power 11 kW
Mains supply types TT / TN / IT
Mains connection CEE plug, red, 16 A, 5‑pin
incl. Neutral conductor
Nominal voltage 230 and 240 V (1‑phase) /
400 and 415 V (3‑phase)
Nominal current (configurable) 6 ‑ 16 A
1‑phase or
3‑phase
Grid frequency 50 Hz
Power consumption in standby 1.9 W (LED dark), 4.2 W (LED bright)
Charging socket Type 2 infrastructure socket with
mechanical lock
Residual current device 20 mA
AC
, 6 mA
DC
Supply line cable cross-section
Min. 2.5 mm
2
RFID (radio frequency identification) 13.56 MHz
WLAN
IEEE 802.11b/g/n | 2.4 GHz
Supported safety standards
WEP, WPA, WPA2, WPA3
Safety class
IP 55
Impact resistance IK08
Dimensions (width x height x depth) 155 x 287 x 109 mm
Weight 2 kg
Use Indoors and outdoors
No direct sunlight
Installation type Suspended
Ambient temperature -25 to +40 °C
Average ambient temperature over 24
hours
Max. 35 °C
Humidity 5 - 95%
Height above sea level 0 - 2,000 m
Wattpi-
lot Go 22 J 2.0
Fronius Wattpilot – technical data Go 22 J 2.0
Max. charging power 22 kW
Mains supply types
TT / TN / IT
Mains connection
CEE plug, red, 32 A, 5‑pin
incl. Neutral conductor
63
EN

Fronius Wattpilot Go 11 J 2.0 Specifications

General

Brand	Fronius
Model	Wattpilot Go 11 J 2.0
Category	Battery Charger
Language	English
